LS-9500HR
STAIRCLIMBER
GK24-00023-XXXX
SN: 148125 & up
1 of 3
rev. 09/16/05
Console Assembl
y
AK24-00280-0001R Eng/Met
AK24-00280-0002 Ger/Met - R&R only
AK24-00280-0004 Frn/Eur
AK24-00280-0005 Spn/Eur
AK24-00280-0006 Itl/Met - R&R only
AK24-00280-0007 Jap/Met - R&R only
AK24-00280-0009 Dut/Met
AK24-00280-0012 Frn/Met - R&R only
AK24-00280-0013 Spn/Met - R&R only
Overlay Bezel
AK24-00314-0001 Eng/Met
AK24-00281-0002 Ger/Met (NLA)
AK24-00281-0004 Frn/Eur/Met (NLA)
AK24-00281-0005 Spn/Eur/Met (NLA)
AK24-00281-0006 Itl/Met (NLA)
AK24-00281-0007 Jap/Met
AK24-00281-0009 Dut/Met
Shroud w/Decal
AK24-00273-0001
Pedal Lever Assembly, Left
AK24-00049-0006
Foot Pedal (2)
0K53-01027-0001
Pedal Lever Assembly, Right
AK24-00049-0005
Boot w/Decal
AK24-00259-0000
Endcap
0K24-01015-0000
Decal
Right
0K24-02020-0001
Left
0K24-02020-0002
Heart Rate Sensor Kit
GK20-00002-0002
Handlebars w/Electrodes (NLA)
SK24-00247-0000
DSP Heart Rate
GK46-00002-0009
Console Case
0K36-01187-0006
Battery Cover
0K36-01035-0006
Vertical Handlebar, Right/Left
0K24-01483-0000
Endcap
0K14-01305-0000
Monocolumn
0K24-01466-0001
