GN032
|
Bicycle Handlebar Mount for Garmin® GPS
The Mobile Mounting Specialists™
®
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
Package Contents:
(1) GN032 - Bicycle handlebar mount with 17mm ball
Step 1.
Step 2.
Compatible with:
• Most Garmin 17mm ball connections (See website for full list)
Safety Precautions
Do not reposition the pedestal while cycling or driving. Arkon
Resources, Inc. does not promote the adjustment of mobile devices
except when the bicycle or vehicle is safely parked or stopped.
Arkon is not responsible for any damages caused to your bicycle, your
device, or yourself due to the installation or use of this product.
!
Precaution: Arkon strongly recommends using a securing
strap to provide extra protection for your device. Failure to
do so may result in damage to your device. Do not operate
portable devices while riding. Arkon Resources, Inc. assumes
no liability for safety of bicycle rider or portable device.
Garmin brand name and Nüvi and StreetPilot product names are trademarks
or registered trademarks of Garmin International. Arkon Resources, Inc. is
not affi liated with Garmin Intl.
Choose a safe location on the handlebars of your bicycle in
which to mount the pedestal.
Using a screwdriver, remove the two mounting screws (A)
in order to release the 17mm ball plate (B) so the mount
can be placed around the handlebars.
Bicycle Handlebar Mounting
Wrap the rubber rings (C) around the handlebar and
reassemble the 17mm ball plate (B) around the rubber rings.
Secure the mount assembly by using the screwdriver to
retighten the two mounting screws.
Step 3.
A
B
B
C
Step 1.
Attaching a Garmin Device to Pedestal
Attach your Garmin device (not included, sold separately)
to the ball head by fi rmly inserting the ball head (C) into the
cavity (D) in the back of the device.
(Cradle / Device
not included)
C
D
GN032
Bicycle Handlebar Mount
Fits handlebars up to 33mm diameter. Compatible with most straight, drop, trekking,
touring, and standard (25.4mm and 26mm) size handlebars. Also for use with golf carts,
ATVs, snowmobiles, hang gliders or other apparatus having cylinder-shaped frames or
posts.
